Image is for your reference only,please check specifications for details

16SVP56M - Panasonic
Manufacturer:
Panasonic
ManyChip's Part#:
MC19032732
Category:
Capacitor
Package:
SMD
Datasheet:
Datasheet 3D Model
Description:
Cap Aluminum Polymer 56uF 16VDC 20% (8 X 6.9mm) SMD 0.045Ω 1890mA 2000H 105℃ T/R
Stock Locations:
Availability:
0 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The 16SVP56M conductive polymer aluminum solid capacitor, developed by Panasonic, can easily handle changes to the input load of a circuit. It can withstand a voltage of 16 VDC. It has 2 terminals. This product is 6.9 mm tall with a diameter of 8 mm. It has a tolerance of 20%. Its leakage current is 179@2Min μA. This conductive polymer aluminum solid capacitor has an operating temperature range of -55 °C to 105 °C.

Show

16SVP56M Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Case/Package	SMD
Voltage Rating (DC)	16.0 V
Capacitance	56 µF
Equivalent Series Resistance (ESR)	0.045 Ω
Capacitance Tolerance	±20 %
Ripple Current	1890 mA
Ripple Current (Low Frequency)	94.5mA @120Hz
Ripple Current (High Frequency)	1.89A @100kHz
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-55 ℃
Voltage Rating	16 V
	Show
Size-Height	6.9 mm
Size-Diameter	8.00 mm
Operating Temperature	-55℃ ~ 105℃
Product Lifecycle Status	Unknown
Packaging	Tape & Reel (TR)
Life (Hours)	2000h @105℃
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99
