AD5241BRZ100 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1047827
Category:
Digital Potentiometer IC
Package:
SOIC-14
Datasheet:
Datasheet 3D Model
Description:
AD5241BRZ100, Digital Potentiometer 100K 256Position Serial-2 Wire, Serial-I2C 14Pin SOIC
Stock Locations:
Availability:
246 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 1.07

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5241BRZ100 is a single-channel digitally-controlled Variable Resistor performs the same electronic adjustment function as a potentiometer, trimmer or variable resistor. Each VR offers a completely programmable value of resistance between the A terminal and the wiper or the B terminal and the wiper. Wiper position programming defaults to midscale at system power on. When powered, the VR wiper position is programmed by an I²C-compatible, 2-wire serial data interface. It has two extra programmable logic outputs available that enable users to drive digital loads, logic gates, LED drivers and analogue switches in their system.
Internal power on midscale preset
I²C-compatible interface with readback capability
Extra programmable logic outputs
Self-contained shutdown feature

Show

AD5241BRZ100 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Voltage (DC)	2.70V (min)
Supply Current	0.0001 mA
Number of Circuits	1 Circuit
Number of Positions	256 Position
Clock Speed	400kHz (max)
Resistance	100 kΩ
Quiescent Current	100 nA
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 105℃
Temperature Coefficient	±30 ppm/℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
