Description
- A must-have for data processing uses, this AD571JD ADC made by Analog Devices will translate analog electrical signals. This device is based on SAR architecture. Its maximum power dissipation is 800 mW. It has a single-ended input signal. This device"s digital interface is parallel. This ADC has a resolution of 10bit. This ADC has an input voltage of 10 V|±5V. Its typical dual supply voltage is -15/5 V, with a minimum of -12/4.5 V and maximum of -16.5/7 V. This ADC has a temperature range of 0 °C to 70 °C.
AD571JD Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 18 Pin |
| Case/Package | CDIP-18 |
| Digital Logic Level | SAR |
| Supply Voltage (DC) | 5.00V (min) |
| Supply Current | 9.00 mA |
| Number of Circuits | 1 Circuit |
| Number of Bits | 10 Bit |
| Power Dissipation | 800 W |
| Sample Rate | 25 ksps |
| Resolution (Bits) | 10.0 Bit |
| Number of ADCs | 1 ADC |
| Number of Inputs | 1 Input |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| Power Dissipation (Max) | 800 mW |
| Number of Input Channels | 1 Channel |
| Supply Voltage (Max) | 15 V |
| Supply Voltage (Min) | 5 V |
| Show | |
| Size-Height | 3.05 mm |
| Operating Temperature | 0℃ ~ 70℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
| Mil-Spec | Yes |
| REACH SVHC Compliance Edition | 2015/12/17 |
