- AD7985BCPZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC2628496
-
Category:Analog to Digital, ADC IC
-
Package:LFCSP-20
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES AD7985BCPZ Analog to Digital Converter, SAR, 16Bit, 2.5MSPS, Single, 4.75V, 5.25V, CSP
-
Stock Locations:
-
Availability:201 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 24.53
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Product Details
- The AD7985 is a 16-bit, 2.5 MSPS successive approximation analog-to-digital converter (SAR ADC). It contains a low power, high speed, 16-bit sampling ADC, an internal conversion clock, an internal reference (and buffer), error correction circuits, and a versatile serial interface port. On the rising edge of CNV, the AD7985 samples an analog input, IN+, between 0 V and REF with respect to a ground sense, IN−. The AD7985 features a very high sampling rate turbo mode (TURBO is high) and a reduced power normal mode (TURBO is low) for low power applications where the power is scaled with the throughput.
- In normal mode (TURBO is low), the SPI-compatible serial interface also features the ability, using the SDI input, to daisy-chain several ADCs on a single 3-wire bus and provide an optional busy indicator. It is compatible with 1.8 V, 2.5 V, and 2.7 V supplies using the separate VIO supply.
- The AD7985 is available in a 20-lead LFCSP with operation specified from −40°C to +85°C.
- Applications
- Battery-powered equipment
- Communications
- ATE
- Data acquisition systems
- Medical instruments
- ### Features and Benefits
- 16-bit resolution with no missing codes
- Throughput: 2.5 MSPS (TURBO high), 2.0 MSPS (TURBO low)
- Low power dissipation
- 15.5 mW at 2.5 MSPS, with external reference
- 28 mW at 2.5 MSPS, with internal reference
- INL: ±0.7 LSB typical, ±1.5 LSB maximum
- SNR
- 88.5 dB, with on-chip reference
- 90 dB, with external reference
- 4.096 V internal reference: typical drift of ±10 ppm/°C
- Pseudo differential analog input voltage range
- 0 V to VREF with VREF up to 5.0 V
- Allows use of any input range
- See data sheet for additional features
AD7985BCPZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 20 Pin |
| Case/Package | LFCSP-20 |
| Supply Voltage (DC) | 4.75V (min) |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Number of Bits | 16 Bit |
| Power Dissipation | 28 mW |
| Sample Rate | 2.5 Msps |
| Resolution (Bits) | 16.0 Bit |
| Number of ADCs | 1 ADC |
| Number of Inputs | 1 Input |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 33 mW |
| Number of Input Channels | 1 Channel |
| Supply Voltage (Max) | 5.25 V |
| Supply Voltage (Min) | 4.75 V |
| Input Voltage | 4.096 V |
| Show | |
| Size-Length | 4 mm |
| Size-Width | 4 mm |
| Size-Height | 0.95 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tray |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| Mil-Spec | No |
| REACH SVHC Compliance Edition | 2015/12/17 |
