AD8362ARUZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC153193
Category:
Detector chip
Package:
TSSOP-16
Datasheet:
Datasheet 3D Model
Description:
RF Detector IC Cellular, GSM, CDMA, TDMA, TETRA 50Hz ~ 3.8GHz -52dBm ~ 8dBm ±0.5dB 16-TSSOP (0.173", 4.4mm Width)
Stock Locations:
Availability:
362 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 11.7

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD8362ARUZ is a TruPwr™ Power Detector that has a 65dB measurement range intended for use in high frequency communication systems and in instrumentation requiring an accurate response to signal power. It is easy to use requiring only a single supply of 5V and a few capacitors. It operates from arbitrarily low frequencies to over 3.8GHz and accepts inputs from -52dBm to +8dBm with crest factors that are typical of quadrature amplitude modulation (QAM) and orthogonal frequency division multiplexing (OFDM) modulation schemes. The detector has 1.3mW power consumption when powered down by a logic high applied to the PWDN pin. It powers up within about 20µs to its nominal operating current of 20mA at 25°C.
Complete, fully calibrated measurement/control system
Accurate rms-to-DC conversion from 50Hz to 3.8GHz
Waveform and modulation independent, such as GSM/CDMA/TDMA
Linear-in-decibels output, scaled 50mV/dB
Law conformance error of 0.5dB
All functions temperature and supply stable
ESD sensitive device, take proper precaution while handling the device.

Show

AD8362ARUZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	TSSOP-16
Frequency	50Hz ~ 3.8GHz
Supply Voltage (DC)	5.50V (max)
Output Voltage	0.1V ~ 4.9V
Supply Current	20 mA
Number of Positions	16 Position
Power Dissipation	500 mW
Bandwidth	2.7 GHz
Thermal Resistance	125 ℃/W
Output Voltage (Max)	1.275 V
Input Power (Max)	8 dBm
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	500 mW
Accuracy	0.5 dB
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	Show
Size-Length	5 mm
Size-Width	4.4 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
