BQ24315DSGR - TI
Manufacturer:
TI
ManyChip's Part#:
MC7971979
Category:
Battery Management IC
Package:
WSON-8
Datasheet:
Datasheet 3D Model
Description:
Charger Front End Protection Overvoltage & Overcurrent Protection IC & Li+ Charger Front-End Protection IC Battery Protection Li-Ion 1500mA 5.5V 8Pin WSON EP T/R
Stock Locations:
Availability:
9,758 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 0.9

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The BQ24315DSGR is an Overvoltage and Overcurrent Protection IC designed to provide protection to Li-ion batteries from failures of the charging circuit. The IC continuously monitors the input voltage, the input current and the battery voltage. The output acts as a linear regulator. The output is regulated to VO(REG)for inputs between VO(REG) and the overvoltage threshold. If an input overvoltage condition occurs, the IC immediately removes power from the charging circuit by turning off an internal switch. In the case of an overcurrent condition, it limits the system current at the threshold value and if the overcurrent persists, switches the pass element OFF after a blanking period. Additionally, the IC also monitors its own die temperature and switches off if it exceeds 140°C. The input overcurrent threshold is user-programmable. The IC can be controlled by a processor and also provides status information about fault conditions to the host.
Input overvoltage, with rapid response in <1µs
User-programmable overcurrent with current limiting
Battery overvoltage
Robust against false triggering due to current transients
Thermal shutdown
Enable input
Status indication - fault condition
Green product and no Sb/Br
Device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

Show

BQ24315DSGR Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	WSON-8
Supply Voltage (DC)	3.30V (min)
Output Voltage	5.5 V
Number of Positions	8 Position
Output Voltage (Max)	5.7 V
Output Voltage (Min)	5.3 V
Output Current (Max)	1 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3.3V ~ 30V
Supply Voltage (Max)	30 V
Supply Voltage (Min)	3.3 V
	Show
Size-Length	2.1 mm
Size-Width	2.1 mm
Size-Height	0.75 mm
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
