Description
- The CSD17559Q5 is a NexFET™ N-channel Power MOSFET designed to minimize losses in synchronous rectification and other power conversion applications. It is suitable for use in point-of-load synchronous buck in networking, telecom, computing systems, active O-ring and hot-swap applications.
- Extremely low resistance
- Ultra-low Qg and Qgd
- Low thermal resistance
- Avalanche rated
- Halogen-free
- Plastic package
- -55 to 150°C Operating junction temperature range
CSD17559Q5 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | 8-VSON-CLIP |
| Number of Positions | 8 Position |
| Polarity | N-Channel |
| Power Dissipation | 3.2 W |
| Threshold Voltage | 1.4 V |
| Drain to Source Voltage (Vds) | 30 V |
| Continuous Drain Current (Ids) | 100A |
| Rise Time | 41 ns |
| Input Capacitance (Ciss) | 9200pF @15V(Vds) |
| Input Power (Max) | 3.2 W |
| Fall Time | 14 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 3.2W (Ta), 96W (Tc) |
| Show | |
| Size-Length | 6.1 mm |
| Size-Width | 5.1 mm |
| Size-Height | 1.05 mm |
| Material | Silicon |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Contains Lead |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/06/15 |
