HMC462 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC1665430
Category:
Amplifier chip
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES HMC462 RF Amplifier IC, 14.5dB Gain / 2.5dB Noise, 2GHz to 20GHz, 5V, Gel Pack
Stock Locations:
Availability:
290 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 52.74

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

Product Details
The HMC462 is a GaAs MMIC PHEMT Low Noise Distributed Amplifier die which operates between 2 and 20 GHz. The amplifier provides 15 dB of gain, 2.0 to 2.5 dB noise figure and +15 dBm of output power at 1 dB gain compression while requiring only 63 mA from a single +5V supply. Gain flatness is excellent at ±0.5 dB from 6 - 18 GHz making the HMC462 ideal for EW, ECM and RADAR applications.
The HMC462 requires a single supply of +5V @ 63 mA and is the self-biased version of the HMC463. The wideband amplifier I/Os are internally matched to 50 Ohms facilitating easy integration into Multi-Chip-Modules (MCMs). All data is with the chip in a 50 Ohm test fixture connected via 0.025mm (1 mil) diameter wire bonds of minimal length 0.31mm (12 mils).
**Applications**
Telecom Infrastructure
Microwave Radio & VSAT
Military & Space
Test Instrumentation
Fiber Optics
### Features and Benefits
Noise Figure: 2 dB @ 10 GHz
Gain: 15 dB
P1dB Output Power: +15 dBm @ 10 GHz
Self-Biased: +5V @ 63 mA
50 Ohm Matched Input/Output
Die Size: 3.12 x 1.38 x 0.1 mm

Show

HMC462 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	3 Pin
Frequency	2GHz ~ 20GHz
Supply Voltage (DC)	5.00V (max)
Supply Current	63 mA
Number of Channels	1 Channel
Power Dissipation	4.5 W
Gain	14.5 dB
Test Frequency	2GHz ~ 20GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	4500 mW
Supply Voltage	5 V
Supply Voltage (Max)	5 V
	Show
Operating Temperature	-55℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
