HMC519 - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC6916642
Category:
Amplifier chip
Package:
Die
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES HMC519 RF Amplifier IC, 14dB Gain / 3.5dB Noise, 18GHz to 32GHz, 2.5V to 3.5V, Gel Pack
Stock Locations:
Availability:
297 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 134.39

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The HMC519 is a high dynamic range GaAs PHEMT MMIC Low Noise Amplifier (LNA) which operates between 18 to 32GHz. The HMC519 provides 15dB of small signal gain, 2.8dB of noise figure and has an output IP3 greater than 23dBm. The chip can easily be integrated into hybrid or MCM assemblies due to its small size. All data is tested with the chip in a 50R test fixture connected via 0.075mm (3mil) ribbon bonds of minimal length 0.31mm (12mil). Two 0.025 mm (1mil) diameter bond wires may also be used to make the RFIN and RFOUT connections.
23dBm OIP3
3V at 65mA Single supply
50R Matched input/output

Show

HMC519 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	8 Pin
Case/Package	Die
Frequency	32000 MHz
Supply Voltage (DC)	2.50V (min)
Supply Current	65 mA
Number of Channels	1 Channel
Number of Positions	8 Position
Power Dissipation	2650 mW
Gain	14 dB
Test Frequency	28GHz ~ 32GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	2650 mW
Supply Voltage	3 V
Supply Voltage (Max)	3.5 V
Supply Voltage (Min)	2.5 V
	Show
Operating Temperature	-55℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
Mil-Spec	Yes
REACH SVHC Compliance Edition	2015/12/17
