Image is for your reference only,please check specifications for details
- ICL7611DCBAZ - Intersil
-
Manufacturer:Intersil
-
ManyChip's Part#:MC49468066
-
Category:Operational Amplifier, OP Amp IC
-
Package:SOIC-8
-
Datasheet:Datasheet 3D Model
-
Description:1.4MHz, Low Power CMOS Operational Amplifiers; PDIP8, SOIC8; Temp Range: 0° to 70°
-
Stock Locations:
-
Availability:822 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.27
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
ICL7611DCBAZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | SOIC-8 |
| Supply Voltage (DC) | 5.00 V |
| Output Current | 40 mA |
| Supply Current | 1 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Common Mode Rejection Ratio | 70 dB |
| Bandwidth | 1.4 MHz |
| Slew Rate | 1.60 V/μs |
| Gain Bandwidth Product | 1.4 MHz |
| Thermal Shutdown | No |
| Input Offset Voltage | 15 mV |
| Input Bias Current | 1 pA |
| Operating Temperature (Max) | 70 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| Gain Bandwidth | 1.4 MHz |
| Minimum CMRR Range | 60 dB |
| Supply Voltage | 1.8 VDC |
| Supply Voltage (Max) | 16 V |
| Supply Voltage (Min) | 2 V |
| Show | |
| Size-Length | 5 mm |
| Size-Width | 4 mm |
| Size-Height | 1.5 mm |
| Operating Temperature | 0℃ ~ 70℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
