Image is for your reference only,please check specifications for details
- MC33179DG - ON Semiconductor
-
Manufacturer:ON Semiconductor
-
ManyChip's Part#:MC8865288
-
Category:Operational Amplifier, OP Amp IC
-
Package:SOIC-14
-
Datasheet:Datasheet 3D Model
-
Description:MC Series 2V/us 36V SMT Low Power Low Noise Operational Amplifier - SOIC-14
-
Stock Locations:
-
Availability:294 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.94
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The MC33179DG is a low power low noise monolithic quad Operational Amplifier employing bipolar technology with innovative high performance concepts. This device family incorporates the use of high frequency PNP input transistors to produce amplifiers exhibiting low input offset voltage, noise and distortion. In addition, the amplifier provides high output current drive capability while consuming only 420µA of drain current per amplifier. The NPN output stage used, exhibits no dead-band crossover distortion, large output voltage swing, excellent phase and gain margins, low open-loop high frequency output impedance, symmetrical source and sink AC frequency performance.
- Large output voltage swing
- ESD Clamps on the inputs increase ruggedness without affecting device performance
- 600R Output drive capability
- 0.15mV (mean) Low offset voltage
- 2.0µV/°C Low TC of input offset voltage
- 0.0024% Low total harmonic distortion
MC33179DG Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 14 Pin |
| Case/Package | SOIC-14 |
| Supply Voltage (DC) | 18.0V (max) |
| Operating Voltage | 2V ~ 18V |
| Halogen Free Status | Halogen Free |
| Supply Current | 1.7 mA |
| Number of Circuits | 4 Circuit |
| Number of Channels | 4 Channel |
| Number of Positions | 14 Position |
| Common Mode Rejection Ratio | 80 dB |
| Bandwidth | 5 MHz |
| Slew Rate | 2.00 V/μs |
| Gain Bandwidth Product | 5 MHz |
| Input Offset Voltage | 1.5 mV |
| Input Bias Current | 100 nA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Gain Bandwidth | 5 MHz |
| Minimum CMRR Range | 80 dB |
| Supply Voltage (Max) | 36 V |
| Supply Voltage (Min) | 4 V |
| Show | |
| Size-Length | 8.75 mm |
| Size-Width | 4 mm |
| Size-Height | 1.5 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
