Image is for your reference only,please check specifications for details

PEH200KB5100MB2 - KEMET Corporation
Manufacturer:
KEMET Corporation
ManyChip's Part#:
MC60888632
Category:
Aluminum Electrolytic Capacitors, Aluminum Capacitors, Capacitors Aluminum
Package:
Radial, CAN
Datasheet:
Datasheet 3D Model
Description:
10mF ±20% 40V 12A(100Hz) Φ36.6mm
Stock Locations:
Availability:
252 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 16.95

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

PEH200 Series has a polarized, all-welded design, heavy duty screw terminals, extended cathode construction, safety vent and plastic insulation. The sealing systems are designed for electrolyte leakage free operation and a very low gas-diffusion rate of electrolyte. Mechanical contact between the winding and the aluminium case allows excellent heat transfer from the winding hot spot to the ambient, which means cooler operation and very high current ratings.
**Features:**
* High CV-Value
* Long Life
* Low ESR and ESL
* Compact Size

Show

PEH200KB5100MB2 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Chassis
Number of Pins	2 Pin
Case/Package	Radial, CAN
Pin Pitch	13 mm
Voltage Rating (DC)	40.0 V
Capacitance	10000 µF
Equivalent Series Resistance (ESR)	0.023 Ω
Capacitance Tolerance	±20 %
Part Family	PEH200
Test Frequency	100Hz
Ripple Current	12 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	40 V
	Show
Size-Length	62.5 mm
Size-Height	62.5 mm
Size-Diameter	35.0 mm
Dielectric Material	Aluminum Electrolytic
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Bulk
Life (Hours)	2000h @85℃
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
