Description

The PMEG10030ELP is a low leakage current planar maximum efficiency general application (MEGA) Schottky Barrier Rectifier with an integrated guard ring for stress protection. It is encapsulated in a small and flat lead surface-mounted device (SMD) plastic package.
High power capability due to clip-bonding technology
Low voltage rectification
High efficiency DC-to-DC conversion
Switch mode power supply
Reverse polarity protection
Low power consumption
AEC-Q101 qualified

Show

PMEG10030ELPX Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package	SOD-128-2
Number of Positions	2 Position
Forward Voltage	770mV @3A
Power Dissipation	2.5 W
Reverse recovery time	8 ns
Forward Current	3 A
Max Forward Surge Current (Ifsm)	70 A
Maximum Forward Voltage (Max)	770mV @3A
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	55 ℃
Junction Temperature	175℃ (Max)
	Show
Operating Temperature	55℃ ~ 175℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
