Description

Provide the ability to switch between voltages by using this step down PTH04T220WAD DC to DC converter and switching regulator module. It has a voltage of 0.69 to 3.6 V. This part has a minimum operating temperature of -40 °C and a maximum of 85 °C. The component will be shipped in tray format.

Show

PTH04T220WAD Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	11 Pin
Case/Package	DIP-11
Supply Voltage (DC)	5.00 V
Power Rating	57 W
Number of Outputs	1 Output
Input Voltage (DC)	2.20V ~ 5.50V
Output Voltage	0.69V ~ 3.6V
Output Current	16 A
Flammability Rating	UL 94 V-0
Number of Regulated Outputs	1 Output
Topology	Buck
Input Voltage (Max)	5.5 V
Input Voltage (Min)	2.2 V
Input Voltage (DC Max)	5.5 V
Input Voltage (DC Min)	2.2 v
Output Voltage (Max)	3.6 V
Output Voltage (Min)	690 mV
Output Current (Max)	16 A
Input Power (Max)	57.6 W
Input Power (Max)	57.6 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Input Voltage	2.2V ~ 5.5V
	Show
Size-Length	25.27 mm
Size-Width	18.92 mm
Size-Height	8.5 mm
Weight	5.30 g
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
