SSM2135SZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC647612
Category:
Audio Amplifier IC
Package:
SOIC-8
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES SSM2135SZ Audio Power Amplifier, AB, 2Channel, ± 2V to ± 18V, SOIC, 8Pins
Stock Locations:
Availability:
94 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 8.49

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The SSM2135SZ is a dual single-supply Audio Op-amp permits excellent performance in portable or low power audio systems, with an operating supply range of 4 to 36V or ±2 to ±18V. The unity-gain stable device has very low voltage noise of 5.2nV/√Hz and total harmonic distortion plus noise below 0.01% over normal signal levels and loads. Such characteristics are enhanced by wide output swing and load drive capability. Unique output stage permits output swing approaching the rail under moderate load conditions. Under severe loading, the SSM2135 still maintains a wide output swing with ultralow distortion. Particularly well suited for computer audio systems and portable digital audio units, the SSM2135 can perform preamplification, headphone and speaker driving and balanced line driving and receiving.
Excellent sonic characteristics
High output drive capability
Unity-gain stable
3.5MHz Gain bandwidth

Show

SSM2135SZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	36.0 V
Supply Current	3.7 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	87 dB
Bandwidth	3.5 MHz
Slew Rate	900 mV/μs
Gain Bandwidth Product	3.5 MHz
Gain	40 dB
Input Offset Voltage	0.2 mV
Input Bias Current	300 nA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	3.5 MHz
Minimum CMRR Range	87 dB
Supply Voltage (Max)	36 V
Supply Voltage (Min)	4 V
	Show
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
