Image is for your reference only,please check specifications for details
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Product Details
- The SSM6322 is an integrated, dual-channel audio amplifier solution that interfaces directly with audio DAC/CODEC, maximizing the fidelity of high fidelity audio signal chains. The highly efficient design of the SSM6322 delivers outstanding audio performance while minimizing power dissipation for maximum battery life in portable applications.
- The SSM6322 features −121 dB THD + N at 1 kHz, along with very low output noise from 20 Hz to 20 kHz. The low power operation, high peak output current, and high PSRR make the SSM6322 an ideal candidate for applications that require high fidelity audio, high dynamic range, precision, and low power. This highly integrated drive solution also reduces development time while reducing board space and minimizing external components.
- The SSM6322 is available in a 24-lead LFCSP package. The SSM6322 operates over the industrial temperature of −40°C to +85°C.
- Applications
- High fidelity headphone driver
- Mobile phones
- Bluetooth speakers & headphones
- Gaming Notebooks and Tablets
- A/V receivers
- Professional audio equipment
- Audio test equipment
- Automobile infotainment system
- ### Features and Benefits
- Flexible architecture to interface with all digital-to-analog converters (DACs)
- Accepts differential current or voltage input (provides single-ended voltage output)
- High output current drive capability
- Greater than 100 mA rms output current
- Accurately reproduces large music transients into heavy loads (16 Ω to 32 Ω)
- Excellent audio fidelity
- −121 dB total harmonic distortion plus noise (THD + N) at 1 kHz, 2 V rms output with ±5 V supply and 32 Ω load
- Low output integrated noise (10 Hz to 22 kHz) of 1.8 μV rms with A-weighted filter
- Supply range: ±3.3 V to ±6 V (typical)
- Low power operation
- Enabled: 60 mW, VCC = +5 V, VEE = −5 V
- Disabled/voice select: <30 μA
- Low power disable mode with high output impedance
- High-Z in power-down mode eliminating voice mode switch from the high fidelity path
- Greater than 87 dB power supply rejection ratio (PSRR) at 20 kHz
- Adjustable input common-mode voltage with resistor programmable reference voltage
- 1.45 V (typical) with no external components
- Capable of two single-pole, low-pass filters in series
- 2.2 nF maximum input capacitor
- Second filter between the GAINx and FILTx pins
- Pop and click noise suppression
- Signal chain integration supports small printed circuit board (PCB) area
- Compact 4 mm × 4 mm LFCSP package
SSM6322 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Show | |
| Product Lifecycle Status | Recommended for New Designs |
