Description
- The STP6NK90ZFP is a SuperMESH™ N-channel Power MOSFET offers Zener-protection and minimized gate charge. The SuperMESH™ is obtained through an extreme optimization of ST"s well established strip-based PowerMESH™ layout. In addition to pushing ON-resistance significantly down, special care is taken to ensure a very good dV/dt capability for the most demanding applications. This MOSFET complements ST full range of high voltage Power MOSFETs.
- 100% Avalanche tested
- Extremely high dV/dt capability
- Very good manufacturing repeatability
STP6NK90ZFP Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 3 Pin |
| Case/Package | TO-220-3 |
| Number of Channels | 1 Channel |
| Number of Positions | 3 Position |
| Drain to Source Resistance (on) (Rds) | 1.56 Ω |
| Polarity | N-Channel |
| Power Dissipation | 30 W |
| Threshold Voltage | 3.75 V |
| Input Capacitance | 1350 pF |
| Drain to Source Voltage (Vds) | 900 V |
| Breakdown Voltage (Drain to Source) | 900 V |
| Continuous Drain Current (Ids) | 5.80 A |
| Rise Time | 45 ns |
| Input Capacitance (Ciss) | 1350pF @25V(Vds) |
| Input Power (Max) | 30 W |
| Fall Time | 20 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 30W (Tc) |
| Show | |
| Size-Length | 10.4 mm |
| Size-Width | 4.6 mm |
| Size-Height | 9.3 mm |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
