Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 2 Pin |
Case/Package | SMB |
Number of Positions | 2 Position |
Forward Voltage | 800mV @2A |
Forward Current | 2 A |
Max Forward Surge Current (Ifsm) | 100 A |
Maximum Forward Voltage (Max) | 800 mV |
Forward Current (Max) | 2 A |
Operating Temperature (Max) | 175 ℃ |
Operating Temperature (Min) | -40 ℃ |
Junction Temperature | -40℃ ~ 175℃ |
Show | |
Size-Length | 4.6 mm |
Size-Width | 3.95 mm |
Size-Height | 1.1 mm |
Operating Temperature | -40℃ ~ 175℃ |
Product Lifecycle Status | Active |
Packaging | Cut Tape (CT) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
REACH SVHC Compliance Edition | 2015/12/17 |
