Description

The ULN2068B is a 50V Quad Darlington Switch designed to interface logic to a wide variety of high current and high voltage loads. This switch contains four NPN Darlington switches delivering up to 1.5A with a specified minimum breakdown of 50V and a sustaining voltage of 35V measured at 100mA. It contains integral suppression diodes for inductive loads have common emitters. The input of switch is compatible with popular 5V logic families and includes a pre-driver stage to reduce loading on the control logic.
Integral suppression diodes
Versions compatible with all popular logic families

Show

ULN2068B Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Voltage Rating (DC)	50.0 V
Current Rating	1.50 A
Output Voltage	50 V
Output Current	1.75 A
Number of Channels	4 Channel
Number of Positions	16 Position
Polarity	NPN
Power Dissipation	1 W
Breakdown Voltage (Collector to Emitter)	50 V
Output Voltage (Max)	50 V
Output Current (Max)	1.5 A
Input Power (Max)	1 W
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-20 ℃
Power Dissipation (Max)	4300 mW
Supply Voltage	50 V
Supply Voltage (Max)	10 V
Input Voltage	15 V
	Show
Size-Length	20 mm
Size-Width	7.1 mm
Size-Height	5.1 mm
Operating Temperature	-20℃ ~ 85℃ (TA)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
