- ZHCS750TA - Diodes
-
Manufacturer:Diodes
-
ManyChip's Part#:MC24297928
-
Category:Schottky Diode
-
RoHS:Lead free / RoHS Compliant
-
Datasheet:Datasheet 3D Model
-
Description:ZHCS750 Series 750mA 40V 100uA High Current Schottky Barrier Diode - SOT-23
-
Stock Locations:
-
Availability:289 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.55
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- ZHCS750 Series 750 mA 40 V 100 uA High Current Schottky Barrier Diode - SOT-23
ZHCS750TA Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SOT-23-3 |
| Voltage Rating (DC) | 40.0 V |
| Current Rating | 750 mA |
| Capacitance | 25.0 pF |
| Output Current | ≤750 mA |
| Forward Voltage | 490mV @750mA |
| Polarity | Standard |
| Power Dissipation | 500 mW |
| Reverse recovery time | 12 ns |
| Forward Current | 1500 mA |
| Maximum Forward Voltage (Max) | 490mV @750mA |
| Forward Current (Max) | 1.5 A |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Junction Temperature | 125℃ (Max) |
| Power Dissipation (Max) | 500 mW |
| Show | |
| Size-Height | 0.98 mm |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
