- 2SC5566 - Sanyo Semicon Device
-
Manufacturer:Sanyo Semicon Device
-
ManyChip's Part#:MC687357539
-
Category:BJTs
-
Package:SOT-89
-
Datasheet:Datasheet 3D Model
-
Description:NPN эпитаксиальные планарные кремниевые транзисторы для применений в DC-DC преобразователях
-
Stock Locations:
-
Availability:277 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0
Updated at 31/10/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Эпитаксиально-планарные кремниевые NPN-транзисторы для применения в DC/DC-преобразователях.
- Области применения: · драйверы реле, драйверы ламп, драйверы двигателей, стробоскопы.
- Особенности: · использование технологий FBET и MBIT; · высокая токовая нагрузочная способность; · низкое напряжение насыщения коллектор-эмиттер; · высокоскоростное переключение; · сверхминиатюрный корпус обеспечивает миниатюризацию конечных изделий; · высокая допустимая рассеиваемая мощность.
2SC5566 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Case/Package | SOT-89 |
| 集电极-基极反向击穿电压V(BR)CBOCollector-Base Voltage(VCBO) | 80V |
| 集电极-发射极反向击穿电压V(BR)CEOCollector-Emitter Voltage(VCEO) | 50V |
| 集电极连续输出电流ICCollector Current(IC) | 4A |
| 截止频率fTTranstion Frequency(fT) | 400MHz |
| 直流电流增益hFEDC Current Gain(hFE) | 200~560 |
| 管压降VCE（sat）Collector-Emitter Saturation Voltage | 85mV |
| 耗散功率PcPower Dissipation | 1.3W |
