AD22103KTZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC245030
Category:
Temperature Sensor
Package:
TO-92-3
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD22103KTZ Temperature Sensor IC, Voltage, ± 0.5℃, 0 °C, +100℃, TO-92, 3Pins
Stock Locations:
Availability:
279 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 6.6

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD22103KTZ is a 3.3V Output Voltage Temperature Sensor with on-chip signal conditioning ideal for use in numerous 3.3V applications. The signal conditioning eliminates the need for any trimming, buffering or linearization circuitry, greatly simplifying the system design and reducing the overall system cost. The output voltage is proportional to the temperature times the supply voltage (ratiometric). Due to its ratiometric nature, the AD22103 offers a cost effective solution when interfacing to an analogue to digital converter. This is accomplished by using the ADC"s power supply as a reference to both the ADC and the AD22103, eliminating the need for and cost of a precision reference.
28mV/°C Temperature coefficient
Accuracy better than 2.5% of full scale
Linearity better than 0.5% of full scale
Minimal self-heating
High level and low impedance output
Reverse supply protected
ESD sensitive device, take proper precaution while handling the device.

Show

AD22103KTZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-92-3
Supply Voltage (DC)	2.70V (min)
Output Voltage	950 mV
Supply Current	600 µA
Number of Positions	3 Position
Number of Bits	8 Bit
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	0 ℃
Accuracy	±0.75 ℃
Supply Voltage	2.7V ~ 3.6V
Supply Voltage (Max)	3.6 V
Supply Voltage (Min)	2.7 V
	Show
Size-Length	5.21 mm
Size-Width	4.19 mm
Size-Height	5.33 mm
Operating Temperature	0℃ ~ 100℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
