AD5446YRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC610939
Category:
Digital to Analog, DAC IC
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD5446YRMZ Digital to Analog Converter, 14Bit, 2.7MSPS, Serial, 2.5V to 5.5V, SOP, 10Pins
Stock Locations:
Availability:
218 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 4.88

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD5446YRMZ is a CMOS 14-bit current output Digital-to-analog Converter (DAC) operating from a single 2.5 to 5.5V power supply, this device is suited for battery-powered and other applications. As a result of the CMOS submicron manufacturing process, this part offers excellent 4-quadrant multiplication characteristics of up to 12MHz. This DAC uses a double-buffered, 3-wire serial interface that is compatible with SPI®, QSPI™, MICROWIRE™ and most DSP interface standards. On power-up, the internal shift register and latches are filled with 0s and the DAC output is at zero scale. The applied external reference input voltage (VREF) determines the full-scale output current. This part can handle ±10V inputs on the reference, despite operating from a single-supply power supply of 2.5 to 5.5V. An integrated feedback resistor (RFB) provides temperature tracking and full-scale voltage output when combined with an external current-to-voltage precision amplifier.
Pin-compatible 12-bit current output DAC
2.7 MSPS Update rate
Power-on reset with brownout detection
0.4µA Typical current consumption
Guaranteed monotonic

Show

AD5446YRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	MSOP-10
Supply Voltage (DC)	5.50V (max)
Number of Outputs	1 Output
Number of Channels	1 Channel
Number of Positions	10 Position
Number of Bits	14 Bit
Power Dissipation	3.30 µW
Sample Rate	2.7 Msps
Resolution (Bits)	14.0 Bit
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Number of DACs	1 DAC
Supply Voltage	2.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2.5 V
	Show
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
