AD637JQ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC317226
Category:
Power Product
Package:
CDIP-14
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD637JQ RMS to DC Converter, High Precision, 0.5%, 8MHz, 0 °C, 70℃, DIP, 14Pins
Stock Locations:
Availability:
550 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 85.58

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD637JQ is a complete, high accuracy, RMS-to-DC Converter that computes the true rms value of any complex waveform. It offers performance that is unprecedented in integrated circuit RMS-to-DC converter and comparable to discrete and modular techniques in accuracy, bandwidth and dynamic range. This computes the true root mean square, mean square or absolute value of any complex AC (or AC plus DC) input waveform and gives an equivalent dc output voltage. The true rms value of a waveform is more useful than an average rectified signal because it relates directly to the power of the signal. The rms value of a statistical signal relates to the standard deviation of the signal. Superior crest factor compensation permits measurements of signals with crest factors of up to 10 with less than 1% additional error.
High accuracy
Wide bandwidth
60dB Output range
Analogue 3-state operation
2.2mA to 350µA Quiescent current reduction
Patented or proprietary protection circuitry, damage may occur on devices subjected to high energy ESD.

Show

AD637JQ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	14 Pin
Case/Package	CDIP-14
Frequency	8 MHz
Power Rating	108 mW
Supply Current	2.2 mA
Number of Positions	14 Position
Power Dissipation	108 mW
Bandwidth	8 MHz
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
3dB Bandwidth	8000 kHz
Power Dissipation (Max)	108 mW
Accuracy	0.5 %
Supply Voltage	3.18 VDC
Supply Voltage (Max)	18 V
Supply Voltage (Min)	3 V
	Show
Size-Height	3.56 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99
