Description
- * V/F conversion to 1 MHz * Reliable monolithic construction * Very low nonlinearity * 0.002% typ at 10 kHz * 0.005% typ at 100 kHz * 0.07% typ at 1 MHz * Input offset trimmable to zero * CMOS- or TTL-compatible * Unipolar, bipolar, or differential V/F * V/F or F/V conversion * Available in surface mount * MIL-STD-883 compliant versions available
AD650SD Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 14 Pin |
| Case/Package | CERDIP-14 |
| Supply Current | 8.00 mA |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Show | |
| Size-Length | 19.94 mm |
| Size-Width | 7.87 mm |
| Size-Height | 3.56 mm |
| Operating Temperature | -55℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
| ECCN Code | EAR99 |
