AD7789BRMZ - ADI
Manufacturer:
ADI
ManyChip's Part#:
MC779559
Category:
Analog to Digital, ADC IC
Package:
MSOP-10
Datasheet:
Datasheet 3D Model
Description:
ANALOG DEVICES AD7789BRMZ Analog to Digital Converter, 24Bit, Single, 2.5V, 5.25V, MSOP
Stock Locations:
Availability:
1,759 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 3.55

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The AD7789BRMZ is a 1-channel 24-bit Low Power Sigma-Delta (Σ-Δ) ADC for low frequency measurement applications. It contains a low noise 24-bit Σ-Δ ADC with one differential input. The complete analogue front end device operates from an internal clock. Therefore, the user does not have to supply a clock source to the device. The output data rate is 1636Hz, which gives simultaneous 50/60Hz rejection. The part operates with a power supply from 2.5 to 5.25 V. When operating from a 3V supply, the power dissipation for the part is 225µW maximum. This ADC is ideal for smart transmitters, temperature measurement and pressure measurement as well as sensor measurement and battery applications.
1.5µV RMS noise
19-bit p-p resolution (21.5-bit effective resolution)
3.5ppm Typical integral nonlinearity
Simultaneous 50 and 60Hz rejection
Internal clock oscillator
VDD monitor channel
ESD sensitive device, take proper precaution while handling the device.

Show

AD7789BRMZ Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	MSOP-10
Supply Voltage (DC)	2.50V (min)
Supply Current	80.0 µA
Number of Channels	1 Channel
Number of Positions	10 Position
Number of Bits	24 Bit
Power Dissipation	0.225 W
Sample Rate	16.6 SPS
Resolution (Bits)	24.0 Bit
Number of ADCs	1 ADC
Number of Inputs	1 Input
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	0.225 mW
Number of Input Channels	1 Channel
Supply Voltage	2.5V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	2.5 V
	Show
Size-Length	3 mm
Size-Width	3 mm
Size-Height	0.85 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2016/06/20
