- AD790AQ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC544704
-
Category:Comparator, Analog Comparator IC
-
Package:CDIP-8
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES AD790AQ Analog Comparator, Single, Precision, 1, 45ns, 4V to 7V, 4.5V to 7V, 4.5V to 33V, DIP, 8Pins
-
Stock Locations:
-
Availability:270 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 17.86
Updated at 02/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- Product Details
- The AD790 is a fast (45 ns), precise voltage comparator, with a number of features that make it exceptionally versatile and easy to use. The AD790 may operate from either a single +5 V supply or a dual ±15 V supply. In the single-supply mode, the AD790"s inputs maybe referred to ground, a feature not found in other comparators. In the dual-supply mode it has the unique ability of handling a maximum differential voltage of 15 V across its input terminals, easing their interfacing to large amplitude and dynamic signals.
- The device is fabricated using Analog Devices" Complementary Bipolar (CB) process - which gives the AD790"s combination of fast response time and outstanding input voltage resolution (1mV max). To preserve its speed and accuracy, the AD790 incorporates a "low glitch" output stage that does not exhibit the large current spikes normally found in TTL or CMOS output stages. Its controlled switching reduces power supply disturbances that can feed back to the input and cause undesired oscillations. The AD790 also has a latching function which makes it suitable for applications requiring synchronous operation.
- The AD790 is available in five performance grades. The AD790J and the AD790K are rated over the commercial temperature range of 0°C to 70°C. The AD790a and AD790B are rated over the industrial temperature range of -40°C to +85°C. The AD790S is rated over the military temperature range of -55°C to +125°C and is available to MIL-STD-883B, Rev. C.
- ### Features and Benefits
- 45 ns max Propagation Delay
- Single 5 V or Dual ±15 V Supply Operation
- CMOS or TTL Compatible Output
- 250 µV max Input Offset Voltage
- 500 µV max Input Hysteresis Voltage
- 15 V max Differential Input Voltage
- Onboard Latch
- 60 mW Power Dissipation
- Available in 8-Pin Plastic and Hermetic Cerdip Packages
- Available in Tape and Reel in Accordance with EIA-481A Standard
AD790AQ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 8 Pin |
| Case/Package | CDIP-8 |
| Supply Current | 6.50 mA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Number of Positions | 8 Position |
| Power Dissipation | 500 mW |
| Common Mode Rejection Ratio | 95 dB |
| Quiescent Current | 10.0 mA |
| Input Offset Voltage | 1.5 mV |
| Input Bias Current | 5000 nA |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 500 mW |
| Supply Voltage (Max) | 7 V |
| Supply Voltage (Min) | 4.5 V |
| Show | |
| Size-Length | 10.29 mm |
| Size-Width | 7.67 mm |
| Size-Height | 3.56 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | Non-Compliant |
| Lead-Free Status | Contains Lead |
| REACH SVHC Compliance Edition | 2015/12/17 |
| HK STC License | NLR |
