- ADAU1401AWBSTZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC905559
-
Category:DSP, Digital Signal Processor
-
Package:LQFP-48
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES ADAU1401AWBSTZ Audio Control, Audio Digital Signal Processor, 2.97V to 3.63V, I2C, SPI, LQFP, 48Pins, -40℃
-
Stock Locations:
-
Availability:299 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 8.15
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The ADAU1401AWBSTZ is a complete single-chip Audio System with 28/56-bit audio DSP, ADCs, DACs and microcontroller-like control interfaces. Signal processing includes equalization, crossover, bass enhancement, multiband dynamics processing, delay compensation, speaker compensation and stereo image widening. This processing can be used to compensate for real-world limitations of speakers, amplifiers and listening environments, providing dramatic improvements in perceived audio quality. The signal processing of the ADAU1401A is comparable to that found in high end studio equipment. Most processing is done in full 56-bit, double-precision mode, resulting in very good low level signal performance. The ADAU1401A is a fully programmable DSP. The easy to use SigmaStudio™ software allows the user to graphically configure a custom signal processing flow using blocks such as biquad filters, dynamics processors, level controls and GPIO interface controls.
- Complete standalone operation
- Self-boot from serial EEPROM
- Auxiliary ADC with 4-input mux for analog control
- GPIOs for digital controls and outputs
- Fully programmable with SigmaStudio graphical tool
ADAU1401AWBSTZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 48 Pin |
| Case/Package | LQFP-48 |
| Number of Channels | 8 Channel |
| Number of Positions | 48 Position |
| RAM Memory Size | 12 KB |
| Power Dissipation | 259.5 mW |
| Power Consumption | 259.5 mW |
| Resolution (Bits) | 24.0 Bit |
| Number of ADCs | 2 ADC |
| Operating Temperature (Max) | 105 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 259.5 mW |
| Number of DACs | 4 DAC |
| Supply Voltage | 2.97V ~ 3.63V |
| Show | |
| Size-Length | 7.2 mm |
| Size-Width | 7.2 mm |
| Size-Height | 1.45 mm |
| Operating Temperature | -40℃ ~ 105℃ (TA) |
| Product Lifecycle Status | Active |
| Packaging | Cut Tape (CT) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
