- ADG419BRMZ - ADI
-
Manufacturer:ADI
-
ManyChip's Part#:MC199644
-
Category:Analog Switch Ic, Analog Switch Multiplexer
-
Package:MSOP-8
-
Datasheet:Datasheet 3D Model
-
Description:ANALOG DEVICES ADG419BRMZ Analog Switch, Single Channel, SPDT, 1Channels, 25Ω, 4.5V to 5.5V, MSOP, 8Pins
-
Stock Locations:
-
Availability:205 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 1.32
Updated at 30/10/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The ADG419BRMZ is a LC²MOS Precision Mini-DIP Analogue Switch designed on an enhanced LC²MOS process that provides low power dissipation yet gives high switching speed, low on resistance and low leakage currents. The on resistance profile is very flat over the full analogue input range, ensuring excellent linearity and low distortion. The part also exhibits high switching speed and high signal bandwidth. CMOS construction ensures ultralow power dissipation, making the parts ideally suited for portable and battery-powered instruments. Each switch of the ADG419 conducts equally well in both directions when on and has an input signal range that extends to the supplies. In the off condition, signal levels up to the supplies are blocked. This exhibits break-before-make switching action.
- 44V Supply maximum rating
- VSS to VDD analogue signal range
- Ultralow power dissipation (<35µW)
- Fast transition time (160ns maximum)
- Break-before-make switching action
- ESD sensitive device, take proper precaution while handling the device.
ADG419BRMZ Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 8 Pin |
| Case/Package | MSOP-8 |
| Supply Voltage (DC) | 12.0V (max) |
| Number of Outputs | 2 Output |
| Contacts Type | SPDT |
| Supply Current | 100 pA |
| Number of Circuits | 1 Circuit |
| Number of Channels | 1 Channel |
| Number of Positions | 8 Position |
| Drain to Source Resistance (on) (Rds) | 25.0 Ω |
| Number of Bits | 1 Bit |
| Power Dissipation | 0.315 W |
| Number of Inputs | 1 Input |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 315 mW |
| Supply Voltage | 4.5V ~ 5.5V |
| Show | |
| Size-Length | 3 mm |
| Size-Width | 3 mm |
| Size-Height | 0.85 mm |
| Operating Temperature | -40℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
