ADS1118IRUGT - TI
Manufacturer:
TI
ManyChip's Part#:
MC24400092
Category:
Analog to Digital, ADC IC
Package:
QFN-10
Datasheet:
Datasheet 3D Model
Description:
16Bit, 860SPS, 4CH ADC with PGA , Voltage Reference, and SPI Interface 10-X2QFN -40℃ to 125℃
Stock Locations:
Availability:
139 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 21.91

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ADS1118IRUGT is a 16-bit Analog-to-Digital converter (ADC) that provides all features necessary to measure the most common sensor signals. The precision, low power ADC integrates a programmable gain amplifier (PGA), voltage reference, oscillator and high-accuracy temperature sensor. This features along with a wide power supply range from 2 to 5.5V, makes the ADC ideally suited for power and space-constrained applications. The PGA offers input ranges from ±256mV to ±6.144V, allowing both large and small signals to be measured with high resolution. An input multiplexer (MUX) allows to measure two differential or four single-ended inputs. The high-accuracy temperature sensor can be used for system-level temperature monitoring or cold-junction compensation for thermocouples. It operates either in continuous-conversion mode or in a single-shot mode that automatically powers down after a conversion. Single-shot mode significantly reduces current consumption during idle periods.
Internal low-drift voltage reference
Internal oscillator
Internal PGA
Four single-ended or two differential inputs
Green product and no Sb/Br

Show

ADS1118IRUGT Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	10 Pin
Case/Package	QFN-10
Supply Voltage (DC)	2.00V (min)
Supply Current	150 µA
Number of Positions	10 Position
Number of Bits	16 Bit
Power Dissipation	0.9 mW
Sample Rate	860 SPS
Power Consumption	300 µW
Number of ADCs	1 ADC
Number of Inputs	2, 4 Input
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Number of Input Channels	2, 4 Channel
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	2 V
	Show
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
