Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Through Hole |
Number of Pins | 8 Pin |
Case/Package | DIP |
Voltage Rating (AC) | 440 V |
Insulation Resistance | 1000 MΩ |
Contacts Type | SPDT |
Power Consumption | 400 mW |
Contact Current Rating | 16 A |
Coil Voltage | 12 VDC |
Coil Current | 33.3 mA |
Coil Resistance | 360 Ω |
Current Rating (Max) | 16 A |
Coil Voltage (DC) | 12 V |
Input Power (Max) | 4 KVA |
Switching Current (Max) | 16 A |
Operating Temperature (Max) | 105 ℃ |
Operating Temperature (Min) | -40 ℃ |
Show | |
Size-Length | 28.8 mm |
Size-Width | 15.7 mm |
Size-Height | 15.7 mm |
Contact Material | Silver Tin Oxide |
Operating Temperature | -40℃ ~ 105℃ |
Product Lifecycle Status | Active |
Packaging | Tube |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
HTS Code | 8536490075 |
ECCN Code | EAR99 |
