Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 2 Pin |
Case/Package (SI) | 1005 |
Case/Package | 0402 |
Capacitance | 115 pF |
Forward Voltage | 2 V |
Wavelength | 590 nm |
Luminous Intensity | 150 mcd |
Viewing Angle | 120° |
Peak Wavelength | 590 nm |
Power Dissipation | 75 W |
Test Current | 20 mA |
Forward Current | 30 mA |
Maximum Forward Voltage (Max) | 2.5 V |
Forward Current (Max) | 30 mA |
Operating Temperature (Max) | 85 ℃ |
Operating Temperature (Min) | -40 ℃ |
Power Dissipation (Max) | 75 mW |
Show | |
Size-Length | 1 mm |
Size-Width | 0.5 mm |
Size-Height | 0.60 mm |
Color | Yellow |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
ECCN Code | EAR99 |
