Description

The B82111BC21 is an axial leaded High Frequency Inductor with ferrite cylinder core. This VHF choke is constructed as single-layer, enamel copper wire, winding ends brought out as leads and polyester insulating sleeve. This inductor"s terminals are made of central axial leads, copper base and hot-dip tinned with pure tin terminations. Supports ±20% of inductance tolerance and is suitable for wave soldering.
High resonant frequency
High rated current
Suitable for wave soldering
ENEC10 approved

Show

B82111BC21 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	2 Pin
Voltage Rating (AC)	500 V
Current Rating	10 A
Capacitance Tolerance	±20 %
Inductance	5 µH
Self Resonant Frequency	175 MHz
Resistance	5.00 mΩ
Resonant Frequency	175 MHz
Inductance Tolerance	±20 %
Test Frequency	1 MHz
DC Resistance (DCR)	5 mΩ
Current Rating (DC)	10 A
Resistance (DC Max)	0.005 Ω
	Show
Operating Temperature	-55℃ ~ 125℃
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
