B82790S0513N201 - Epcos
Manufacturer:
Epcos
ManyChip's Part#:
MC1730540
Category:
Filter
Package:
7.1mm x 6mm x 4.9mm
Datasheet:
Datasheet 3D Model
Description:
EPCOS B82790S0513N201 Choke, Common Mode, 51µH, B82790S0 Series, 0.14Ω, 500mA, 7.1mm x 6mm x 4.9mm
Stock Locations:
Availability:
10,807 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 5.66

Updated at 17/06/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The B82790S0 series from EPCOS are common mode chokes. It functions the suppression of asymmetrical and symmetrical interference coupled on lines. The high frequency portion of symmetrical data signal are decreased until the EMC problems are reduced significantly.
Current compensated ring core double choke
Rated voltage of 42VAC (50/60 Hz) / 80VDC
Ferrite core and sector winding
Suitable for reflow soldering
Automotive grade AEC-Q200 qualified
PPS case (UL 94 V-0)
0.025mH and 0.051mH Inductance values available
Rated current of 500mA
7.1mm x 6mm x 4.9mm case size

Show

B82790S0513N201 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	4 Pin
Case/Package	7.1mm x 6mm x 4.9mm
Voltage Rating (DC)	80.0 V
Current Rating	500 mA
Flammability Rating	UL 94 V-0
Inductance	51 µH
Resistance	300 mΩ
Shielding	No
Test Frequency	100 kHz
DC Resistance (DCR)	≤160.0 mΩ
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	42 VAC
	Show
Size-Length	9 mm
Size-Width	6 mm
Size-Height	5.2 mm
Product Lifecycle Status	Not For New Designs
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
