Description

The TDK C series commercial grade multilayer ceramic chip capacitor is Class 2, X7R dielectric material with perfect layering technique which ensures the precise placing of dielectric and electrode layers as well as the multilayer technology. High capacitance has been achieved through precision technologies that enable the use of multiple thinner ceramic dielectric layers. Typical applications include smoothing and decoupling circuits.
Capacitance values ranging from 0.5pF to 100µF based on dielectric material
Case sizes 0402, 0603, 1005, 1608, 2012, 3216, 3225, 4532 and 5750 are available
DC voltage rating of 4V to 50V
Low ESL and excellent frequency characteristics
Low self heating and high ripple resistance due to low ESR
High temperature range of -55°C to 125°C
Monolithic structure ensures superior mechanical strength and reliability

Show

C2012X7R1A475K125AC Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Surface Mount
Number of Pins	2 Pin
Case/Package (SI)	2012
Case/Package	0805
Voltage Rating (DC)	10 V
Insulation Resistance	10 GΩ
Capacitance	4.7 µF
Capacitance Tolerance	±10 %
Dielectric Characteristic	X7R
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Voltage Rating	10 V
	Show
Size-Length	2 mm
Size-Width	2 mm
Size-Height	1.25 mm
Size-Thickness	1.25 mm
Material	X7R/-55℃~+125℃
Dielectric Material	Ceramic Multilayer
Operating Temperature	-55℃ ~ 125℃
Temperature Coefficient	±15 %
Product Lifecycle Status	Active
Packaging	Cut Tape (CT)
Minimum Packing Quantity	3000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
