Image is for your reference only,please check specifications for details
- CB101 - XP Power
-
Manufacturer:XP Power
-
ManyChip's Part#:MC200827984
-
Category:DC to DC Converter, DC/DC Converter
-
Package:DIP-8
-
Datasheet:Datasheet 3D Model
-
Description:XP POWER CB101 Non Isolated POL DC-DC Converter, Adjustable, 1W, 0 V, 10kV, 100μA
-
Stock Locations:
-
Availability:6 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 648.59
Updated at 29/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- CB series miniature, regulated high voltage DC to DC converters provide clean and reliable high voltage in a shielded, PC mount package. These modules exhibit very low ripple, noise and EMI/RFI by utilizing a quasi-sinewave oscillator, shielded transformer and excellent filtering techniques. The CB Series features current and voltage monitoring, built-in protection against programming overvoltage and thermal shutdown. Typical applications include electrophoresis, capacitor charging, field generation, spectrometry, deflection plates, test instrumentation and image intensifier.
- 0 to 100% programmable output
- High stability of less than 0.01%/hr/8hrs
- Ideal for integration into compact and sensitive equipments
- Sealed to withstand immersion cleaning process
- Plated steel case with isolated case ground
- High reliability (MTBF >2.6 million hours per Bellcore TR-332)
- External gain adjust for calibration
- Built-in 5V reference voltage
- Isolated steel enclosure featuring a separate grounding pin
CB101 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Case/Package | DIP-8 |
| Power Rating | 1 W |
| Number of Outputs | 1 Output |
| Output Voltage | ≥0.00 V |
| Input Voltage (Max) | 15.5 V |
| Input Voltage (Min) | 11.5 V |
| Input Voltage (DC Max) | 16 V |
| Input Voltage (DC Min) | 11.5 v |
| Output Voltage (Min) | 0 V |
| Output Current (Max) | 100 µA |
| Input Power (Max) | 1 W |
| Show | |
| Size-Width | 31.75 mm |
| Size-Height | 15.24 mm |
| Operating Temperature | -10℃ ~ 60℃ |
| Product Lifecycle Status | Active |
| RoHS | Exempt |
| Lead-Free Status | Exempt |
