Description

The ZLLS400 is a surface mount Schottky Barrier Diode with matte tin annealed over alloy 42 lead frame terminals, UL94V-0 flame-rated case and cathode band terminal connection. Solderable terminals as per MIL-STD-202, method 208 standard. The Schottky diode offers users an excellent performance combination comprising high current operation, extremely low leakage and low forward voltage ensuring suitability for applications requiring efficient operation at higher temperature (above 85°C).
Low equivalent on resistance
Extremely low leakage (10µA at 30V)
High current capability (IF=0.52A)

Show

ZLLS400 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	2 Pin
Case/Package	SOD-323
Number of Positions	2 Position
Forward Voltage	0.8 V
Forward Current	520 mA
Max Forward Surge Current (Ifsm)	12 A
Maximum Forward Voltage (Max)	610 mV
Forward Current (Max)	520 mA
Operating Temperature (Max)	150 ℃
	Show
RoHS	RoHS Compliant
