- TPS61235PRWLR - TI
-
Manufacturer:TI
-
ManyChip's Part#:MC43629808
-
Category:Switching Controller
-
Package:VQFN-9
-
Datasheet:Datasheet 3D Model
-
Description:Conv DC-DC 2.3V to 4.5V Synchronous Step Up Single-Out 5.1V 8A 9Pin VQFN-HR EP T/R
-
Stock Locations:
-
Availability:280 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.81
Updated at 17/06/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The TPS6123x is a high current, high efficiency synchronous boost converter with constant output current feature for single cell Li-Ion and Li-polymer battery powered products, in a wide range of power bank, tablet, and other portable devices. The IC integrates 14-mΩ/14-mΩ power switches and is capable of delivering up to a 3.5-A output current for 3.3-V to 5-V conversion with up to 97% high efficiency. The device supports a programmable constant output current to control power delivery, so to save power path components and lower total system thermal dissipation effectively.
- The device only consumes a 10-µA quiescent current under a light load condition, and can report load status to the system, which make it very suitable for Always-On applications. With the TPS6123x, a simple and flexible system design can be achieved, eliminating external power path components, saving PCB space, and reducing BOM cost.
- In shutdown, the output is completely disconnected from the input, and current consumption is reduced to less than 1 µA. Other features like soft start control, reverse current blocking, over voltage protection, and thermal shutdown protection are built-in for system safety.
- The devices are available in a 2.5-mm × 2.5-mm VQFN package.
TPS61235PRWLR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 9 Pin |
| Case/Package | VQFN-9 |
| Number of Outputs | 1 Output |
| Output Voltage | 5.1 V |
| Output Current | 8 A |
| Quiescent Current | 10.0 µA |
| Number of Regulated Outputs | 1 Output |
| Switching Frequency | 1 MHz |
| Switching Current | 8 A |
| Input Voltage (Max) | 4.5 V |
| Input Voltage (Min) | 2.3 V |
| Output Voltage (Min) | 5.1 V |
| Output Current (Max) | 8 A |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Supply Voltage (Min) | 2.3 V |
| Input Voltage | 2.3V ~ 4.5V |
| Show | |
| Operating Temperature | -40℃ ~ 125℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| ECCN Code | EAR99 |
