Description
- Texas Instruments" CD4023BE logic gates will allow you to implement basic logic functions within your electronic circuit. This gate has an operating temperature range of -55 °C to 125 °C. This device comes in tube packaging. This device has a typical operating supply voltage of 3.3|5|9|12|15 V. Its minimum operating supply voltage of 3 V, while its maximum is 18 V.
CD4023BE Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Through Hole |
| Number of Pins | 14 Pin |
| Case/Package | DIP-14 |
| Supply Voltage (DC) | 3.00V ~ 18.0V |
| Operating Voltage | 3V ~ 18V |
| Number of Outputs | 1 Output |
| Output Current | 6.8 mA |
| Number of Circuits | 3 Circuit |
| Number of Channels | 3 Channel |
| Number of Positions | 14 Position |
| Number of Bits | 3 Bit |
| Propagation Delay Max (tpd) | 200 ns |
| Voltage Nodes | 5.00 V, 10.0 V, 15.0 V |
| Power Dissipation | 500 mW |
| Quiescent Current | 20.0 nA |
| Number of Gates | 3 Gate |
| Input Capacitance | 5.00 pF |
| Output Current Drive | -1.00 mA |
| Number of Inputs | 3 Input |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Supply Voltage | 3V ~ 18V |
| Supply Voltage (Max) | 18 V |
| Supply Voltage (Min) | 3 V |
| Show | |
| Size-Length | 19.3 mm |
| Size-Width | 6.35 mm |
| Size-Height | 4.57 mm |
| Operating Temperature | -55℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| REACH SVHC Compliance Edition | 2011/12/19 |
