Description
- The DCP020503U is a family of 2W isolated unregulated DC/DC Converter Module. Requiring a minimum of external components and including on-chip device protection, the DCP02 series of device provides extra features such as output disable and synchronization of switching frequencies. This combination of features and small size makes the DCP02 series of device suitable for a wide range of applications and is an easy-to-use solution in applications requiring signal path isolation.
- Device-to-device synchronization
- EN55022 Class B EMC performance
- 1kV Operational isolation
- This product has operational isolation and is intended for signal isolation only. It should not be used as a part of a safety isolation circuit requiring reinforced isolation.
DCP020503U Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 28 Pin |
| Case/Package | SOP-12 |
| Frequency | 800 kHz |
| Supply Voltage (DC) | 5.50V (max) |
| Power Rating | 2 W |
| Number of Outputs | 1 Output |
| Input Voltage (DC) | 5.00 V |
| Output Voltage | 3.3 V |
| Output Current | 606 mA |
| Number of Positions | 28 Position |
| Quiescent Current | 18.0 mA |
| Number of Regulated Outputs | 1 Output |
| Isolation Voltage | 1 kV |
| Switching Frequency | 800 kHz |
| Input Voltage (Max) | 5.5 V |
| Input Voltage (Min) | 4.5 V |
| Output Current (Max) | 606 mA |
| Input Power (Max) | 2 W |
| Operating Temperature (Max) | 85 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Input Voltage | 4.5V ~ 5.5V |
| Show | |
| Size-Length | 17.7 mm |
| Size-Width | 7.40 mm |
| Size-Height | 2.35 mm |
| Operating Temperature | -40℃ ~ 85℃ |
| Product Lifecycle Status | Active |
| Packaging | Tube |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
