Image is for your reference only,please check specifications for details
- DZ5CE010 - Schneider Electric
-
Manufacturer:Schneider Electric
-
ManyChip's Part#:MC59583264
-
Category:Circular Connector, Connector Circular
-
Datasheet:Datasheet 3D Model
-
Description:SCHNEIDER ELECTRIC / TELEMECANIQUE DZ5CE010 Клемма с проволочной наконечником, серия DZ5, 18 AWG, 1 мм², красная, пластиковая
-
Stock Locations:
-
Availability:10,670 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.06
Updated at 04/09/2026 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- DZ5CE010 — это концевая клемма для кабеля; она оснащена лужёной медной наконечником и изолированной оболочкой. Медный наконечник удерживает жилы многожильного провода и обеспечивает надёжное соединение. Изолированная пластиковая оболочка предотвращает короткое замыкание между соседними соединениями.
- Медный наконечник, лужёный в соответствии с ISO 1337
- Пластиковая изолированная оболочка, не содержащая галогенов
- Рабочая температура окружающего воздуха: от −20 до 105 °C
- Одножильный тип
- Сечение кабеля: 1 мм²
- Средний размер
DZ5CE010 Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Wire Gauge | 18.0 AWG |
| Contact Plating | Tin |
| Show | |
| Size-Length | 14 mm |
| Size-Height | 13.5 mm |
| Color | Red |
| Contact Material | Copper |
| Material | Copper |
| Insulation Material | Plastic |
| Product Lifecycle Status | Active |
| Packaging | Bulk |
| RoHS | RoHS Compliant |
| REACH SVHC Compliance | No SVHC |
