Description

The FDPF18N50 is an UniFET™ high voltage MOSFET produced based on planar stripe and DMOS technology. It is tailored to reduce ON-state resistance and to provide better switching performance and higher avalanche energy strength. This device family is suitable for switching power converter applications such as power factor correction (PFC), flat panel display (FPD) TV power, ATX and electronic lamp ballasts.
100% Avalanche tested
45nC Typical low gate charge
25pF Typical low Crss

Show

FDPF18N50 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.22 Ω
Polarity	N-Channel
Power Dissipation	38.5 W
Threshold Voltage	5 V
Input Capacitance	2.86 nF
Gate Charge	60.0 nC
Drain to Source Voltage (Vds)	500 V
Breakdown Voltage (Drain to Source)	500 V
Breakdown Voltage (Gate to Source)	±30.0 V
Continuous Drain Current (Ids)	18.0 A
Rise Time	165 ns
Input Capacitance (Ciss)	2860pF @25V(Vds)
Input Power (Max)	38.5 W
Fall Time	90 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	38.5W (Tc)
	Show
Size-Length	10.16 mm
Size-Width	4.7 mm
Size-Height	9.19 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
