ICL7107CPL+ - Maxim Integrated
Manufacturer:
Maxim Integrated
ManyChip's Part#:
MC8418888
Category:
Analog to Digital, ADC IC
Package:
DIP-40
Datasheet:
Datasheet 3D Model
Description:
ADC, Dual-Slope, 23Bit, 1 Func, 1Channel, Parallel, Word Access, CMOS, PDIP40, PLASTIC, DIP-40
Stock Locations:
Availability:
348 pcs In Stock
MOQ:
1 pcs
Unit Price:
$ 10.05

Updated at 01/11/2025 10:30:15(UTC+8)

Certifications

ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.

Description

The ICL7107CPL+ is a monolithic 31/2 digit analogue to digital converter (ADC) in 40 pin DIP package. It has very high input impedance and requires no external display drive circuitry. Onboard active components include polarity and digit drivers, segment decoders, voltage reference and clock circuit. The ICL7107 will directly drive common anode light emitting diode (LED) display. Versatility and accuracy are inherent features of this converter. The dual slope conversion technique automatically rejects interference signals common in industrial environments. The true differential input and reference are particularly useful when making ratiometric measurements (ohms or bridge transducers). The device has zero integrator phase to eliminate overrange hangover and hysteresis effects. The ICL7107 offers high accuracy by lowering rollover error to less than one count and zero reading drift to less than 1µV/°C. It is used in a wide range of digital panel meter applications.
Monolithic CMOS design
Operating temperature range from 0°C to 70°C
First reading recovery from overrange
Onboard display drive capability, no external circuitry required
High impedance CMOS differential inputs
Low noise (< 15µVP-P) without hysteresis or overrange hangover
Common mode rejection ratio (CMRR) of 50µV/V and segment sinking current of 16mA
0.8mA V+ supply current, 0.6mA V- supply current and 8mA segment sinking current
True polarity indication for precision null applications
