Attribute | Attribute Value |
---|---|
Datasheet | Datasheet |
3D Model | 3D Model |
Mounting Style | Surface Mount |
Number of Pins | 6 Pin |
Case/Package | PQFN-8 |
Power Rating | 2.1 W |
Number of Positions | 6 Position |
Drain to Source Resistance (on) (Rds) | 0.013 Ω |
Polarity | N-Channel |
Power Dissipation | 2.1 W |
Part Family | IRFHS8342 |
Threshold Voltage | 1.8 V |
Drain to Source Voltage (Vds) | 30 V |
Continuous Drain Current (Ids) | 8.8A |
Rise Time | 15 ns |
Input Capacitance (Ciss) | 600pF @25V(Vds) |
Input Power (Max) | 2.1 W |
Fall Time | 5 ns |
Operating Temperature (Max) | 150 ℃ |
Operating Temperature (Min) | -55 ℃ |
Power Dissipation (Max) | 2.1W (Ta) |
Show | |
Operating Temperature | -55℃ ~ 150℃ (TJ) |
Product Lifecycle Status | Active |
Packaging | Tape & Reel (TR) |
RoHS | RoHS Compliant |
Lead-Free Status | Lead Free |
