Description

The IRFP9240PBF is a -200V P-channel Power MOSFET, third generation power MOSFET provides the designer with the best combination of fast switching, ruggedized device design and low on-resistance.
Dynamic dV/dt rating
Repetitive avalanche rated
Easy to parallel
Simple drive requirement
Isolated central mounting hole

Show

IRFP9240PBF Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-247-3
Voltage Rating (DC)	-200 V
Current Rating	-12.0 A
Power Rating	150 W
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.5 Ω
Polarity	P-Channel
Power Dissipation	150 W
Threshold Voltage	4 V
Drain to Source Voltage (Vds)	200 V
Breakdown Voltage (Drain to Source)	-200 V
Continuous Drain Current (Ids)	12.0 A, -12.0 A
Rise Time	43 ns
Input Capacitance (Ciss)	1200pF @25V(Vds)
Input Power (Max)	150 W
Fall Time	38 ns
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	150 W
	Show
Size-Length	15.87 mm
Size-Width	5.31 mm
Size-Height	20.7 mm
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
Minimum Packing Quantity	500
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99
