Description

Description:
Available in three different voltage classes (60V, 80V and 100V), Infineon’s new logic level power MOSFETs are highly suitable for wireless charging, telecom and adapter applications. The PQFN 2x2 package is especially suited for high speed switching and form factor critical applications. It enables higher power density and improved efficiency as well as significant space saving.
Summary of Features:
Lowest FOM (R DS(on) x Q g/gd)
Optimized Q g, C oss, and Q rr for fast switching
Logic level compatibility
Tiny PQFN 2x2mm package
Benefits:
Smallest package footprint
Higher power density designs
Higher switching frequency
Reduced parts count wherever 5V supplies are available
Driven directly from microcontrollers (slow switching)
System cost reduction
Target Applications:
Wireless charging
Telecom
Adapter

Show

IRL100HS121 Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	6 Pin
Case/Package	PG-TSDSON-6
Number of Positions	6 Position
Drain to Source Resistance (on) (Rds)	0.034 Ω
Power Dissipation	2.5 W
Threshold Voltage	1.7 V
Drain to Source Voltage (Vds)	100 V
Rise Time	21 ns
Input Capacitance (Ciss)	440pF @50V(Vds)
Fall Time	10.7 ns
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	2500 mW
	Show
Material	Silicon
Operating Temperature	-55℃ ~ 175℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
