Description
- The IRLML5103TRPBF is a HEXFET® single P-channel Power MOSFET utilizes advanced processing techniques to achieve extremely low ON-resistance per silicon area. This benefit combined with the fast switching speed and ruggedized device design, provides an extremely efficient and reliable operation.
- Generation V technology
- Low profile (<1.1mm)
- Fast switching
- Low static drain-to-source ON-resistance
- Dynamic dV/dt rating
- Fully avalanche rating
- Halogen-free
IRLML5103TRPBF Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SOT-23-3 |
| Power Rating | 0.54 W |
| Number of Positions | 3 Position |
| Drain to Source Resistance (on) (Rds) | 0.6 Ω |
| Polarity | P-Channel |
| Power Dissipation | 540 mW |
| Threshold Voltage | 1 V |
| Input Capacitance | 75 pF |
| Drain to Source Voltage (Vds) | 30 V |
| Continuous Drain Current (Ids) | 0.76A |
| Rise Time | 8.2 ns |
| Input Capacitance (Ciss) | 75pF @25V(Vds) |
| Input Power (Max) | 540 mW |
| Fall Time | 16 ns |
| Operating Temperature (Max) | 150 ℃ |
| Operating Temperature (Min) | -55 ℃ |
| Power Dissipation (Max) | 540 mW |
| Show | |
| Size-Length | 3.04 mm |
| Size-Width | 1.4 mm |
| Size-Height | 1.02 mm |
| Operating Temperature | -55℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2015/12/17 |
