Image is for your reference only,please check specifications for details
- IRS23364DSPBF - Infineon
-
Manufacturer:Infineon
-
ManyChip's Part#:MC13726012
-
Category:FET Driver
-
Package:SOIC-28
-
Datasheet:Datasheet 3D Model
-
Description:MOSFET DRVR 600V 0.35A 6Out Hi/Lo Side 3-Phase Brdg Non-Inv 28Pin SOIC W Tube
-
Stock Locations:
-
Availability:225 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 2.04
Updated at 01/11/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- The IRS23364DSPBF is a high voltage high speed power MOSFET and IGBT Gate Driver with three high-side and low-side referenced output channels for 3-phase applications. Proprietary HVIC and latch immune CMOS technologies have been implemented in a rugged monolithic structure. The floating logic input is compatible with standard CMOS or LSTTL outputs. An open-drain FAULT signal is provided to indicate that a fault has occurred. Fault conditions are cleared automatically after a delay programmed externally via an RC network connected to the RCIN input. The output driver features a high-pulse current buffer stage designed for minimum driver cross-conduction. Shoot-through protection circuitry and a minimum dead-time circuitry have been integrated into this IC. Propagation delays are matched to simplify the HVICs use in high frequency applications. The floating channels can be used to drive N-channel power MOSFETs or IGBTs in the high-side configuration, which operate up to 600V.
- Drives up to 6-IGBT/MOSFET power devices
- Integrated bootstrap functionality
- Over-current protection
- Over-temperature shutdown input
- Advanced input filter
- Integrated dead-time protection
- Shoot-through (cross-conduction) protection
- Under-voltage lockout for VCC and VBS
- Enable/disable input and fault reporting
- Adjustable fault clear timing
- Separate logic and power grounds
- Tolerant to negative transient voltage
- Designed for use with bootstrap power supplies
- Matched propagation delays for all channels
- 3.3V Input logic compatible
- -40 to 125°C Operating temperature range
- ESD sensitive device, take proper precaution while handling the device.
IRS23364DSPBF Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 28 Pin |
| Case/Package | SOIC-28 |
| Supply Voltage (DC) | 11.5V (min) |
| Power Rating | 1.6 W |
| Rise/Fall Time | 125ns, 50ns |
| Number of Outputs | 6 Output |
| Output Voltage | 600 V |
| Output Current | 200.350 mA |
| Number of Channels | 6 Channel |
| Number of Positions | 28 Position |
| Power Dissipation | 1600 mW |
| Fall Time (Max) | 75 ns |
| Fall Time (Max) | 190 ns |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | -40 ℃ |
| Power Dissipation (Max) | 1600 mW |
| Supply Voltage | 11.5V ~ 20V |
| Supply Voltage (Max) | 20 V |
| Supply Voltage (Min) | 11.5 V |
| Show | |
| Size-Length | 18.1 mm |
| Size-Width | 7.6 mm |
| Size-Height | 2.35 mm |
| Operating Temperature | -40℃ ~ 150℃ (TJ) |
| Product Lifecycle Status | Active |
| Packaging | Each |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance Edition | 2015/12/17 |
| ECCN Code | EAR99 |
