Image is for your reference only,please check specifications for details
- L78L05ACUTR - ST Microelectronics
-
Manufacturer:ST Microelectronics
-
ManyChip's Part#:MC24317
-
Category:Voltage Regulator
-
Package:SOT-89-3
-
Datasheet:Datasheet 3D Model
-
Description:Linear Voltage Regulator, 7805, Fixed, 10V To 30V In, 5V And 0.1A Out, SOT-89-3
-
Stock Locations:
-
Availability:337 pcs In Stock
-
MOQ:1 pcs
-
Unit Price:$ 0.05
Updated at 25/10/2025 10:30:15(UTC+8)
Certifications
ManyChip is committed to product quality and safety with ISO 9001, ISO 13485, ISO 45001, UL, RoHS, CQC and REACH certifications.
Description
- This three-terminal positive regulator employs internal current limiting and thermal shutdown, making it essentially indestructible. If adequate heat-sink is provided, it can deliver up to 100 mA output current. It is intended as fixed voltage regulator in a wide range of applications including local or on-card regulation for elimination of noise and distribution problems associated with single-point regulation. In addition, it can be used with power pass elements to make high-current voltage regulators.
- Output current up to 100 mA
- Thermal overload protection
- Short-circuit protection
- No external components are required
L78L05ACUTR Specifications
| Attribute | Attribute Value |
|---|---|
| Datasheet | Datasheet |
| 3D Model | 3D Model |
| Mounting Style | Surface Mount |
| Number of Pins | 3 Pin |
| Case/Package | SOT-89-3 |
| Number of Outputs | 1 Output |
| Input Voltage (DC) | 20.0V (max) |
| Output Voltage | 5 V |
| Output Current | 100 mA |
| Supply Current | 5.5mA ~ 6mA |
| Number of Positions | 3 Position |
| Quiescent Current | 6 mA |
| voltage rating | 1.7V @40mA |
| Input Voltage (Max) | 30 V |
| Input Voltage (Min) | 10 V |
| Output Voltage (Min) | 5 V |
| Output Current (Max) | 0.1 A |
| Operating Temperature (Max) | 125 ℃ |
| Operating Temperature (Min) | 0 ℃ |
| Accuracy | ±4 % |
| Number of Output Channels | 1 Channel |
| Input Voltage | 30 V |
| Show | |
| Size-Length | 4.6 mm |
| Size-Width | 2.6 mm |
| Size-Height | 1.6 mm |
| Operating Temperature | 0℃ ~ 125℃ |
| Product Lifecycle Status | Active |
| Packaging | Tape & Reel (TR) |
| RoHS | RoHS Compliant |
| Lead-Free Status | Lead Free |
| REACH SVHC Compliance | No SVHC |
| ECCN Code | EAR99 |
| HK STC License | NLR |
