Description

Simple Drive Requirement Small Package Outline Surface Mount Device Pb-Free package is available

Show

LP2301LT1G Specifications

Attribute	Attribute Value

Datasheet	Datasheet
3D Model	3D Model
Number of Pins	3 Pin
Case/Package	SOT-23
Drain to Source Resistance (on) (Rds)	0.1 Ω
Polarity	P
Threshold Voltage	0.4 V
Drain to Source Voltage (Vds)	20 V
Continuous Drain Current (Ids)	2.3A
Rise Time	3.73 ns
Fall Time	6.19 ns
	Show
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Unknown
Minimum Packing Quantity	3000
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
